钢圈机（机械式、数控式）Bra Wire Cutting Machine
|
该产品吸收了国内业界先进机型的优点，注重在机械结构上进行突破。
主机设计原理综合考虑机械操作功能的实用性和简易性，操作方面采用螺纹对凸**以及活动刀头进行自动调节，适应不同规格弧度大小的钢圈产品，极大的满足内衣厂商对钢圈机生产的多种需求。 本机具备螺纹无级调速，工作性能稳定、精度高、速度快、操作方便等特点。 用途：
该机适用于多种不同规格弧度的钢圈生产。
特点：本机配有多种钢圈调节方式，性能稳定，精度高，速度快。
技术参数：
1.电源/功率：：380V/2.2KW
2.产品尺寸：厚度：0.8mm~1.2mm; 宽度：2.0mm~2.5mm
3.主机尺寸： 900mm×1000mm×900mm
4.适用物料：回弹性不锈钢丝、炭钢等。
5.适用产品范围：胸圈、钢圈的成型加工
6.重量：250KG
7.生产量：50~60个/分钟
|
This machine absorbed the merits of the advanced machine types and made a breakthrough in its structure. The design principle of the main engine took the practicability and simplification into consideration. It adopts the screw thread get along with circular cam and the movable tool bit to regulate automatically, which can be suitable for the steel products with different specification and radian so as to satisfy the requirements of the underwear manufacturers. This machine bears the infinitely adjust speed, steady operation, fast and convenient to operate.
Function：
It is suitable for producing the steel wires with different specification and radians.
Features: This machine is equipped with several adjusting modes for steel wires and it is of steady function, high precision and rapid speed.
Technical parameter:
＼
1. Power supply/power:380V/2.2KW
2. Diameter of the cut wires: depth :0.8mm~1.2mm; width: 2.0mm~2.5mm
3. Dimension of the machine: 900mm×1000mm×900mm
4. Applicable materials: elastic stainless steel, charcoal steel and etc.
5. Applicable range of the products: the cutting of bra wire
6. Weight: 250KG (approx. weight)
7. Productivity: 50~60 pieces/min欢迎广大用户来电咨询，联系人：陈佩英（手机：15817935595），谢谢支持！
